Tubo hidraulike me 6 shtresa Teli R13
TIPARET KRYESORE :
SAE 100R13. Kjo tubo eshte e perbere prej 6 shtresash teli spirale me drejtime te alternuara. Goma e tubos sintetike dhe rezistente i jep nje jetegjatesi tubos ndaj vajrave dhe ambjentit ku do te montohet.
FUSHA E APLIKIMIT :
Kjo tubo mund te perdoret per lengje hidraulike me baze nafte
TEMPERATURA E PUNES :
Nga -40 grade celcius deri ne +121 grade celcius.
| DN | Hose I.D | Wire O.D | Hose O.D | Working Pressure | Burst Pressure | Minimum Bend Radius | |||
| inch | mm | mm | mm | Mpa | psi | Mpa | psi | mm | |
| 19 | 3/4″ | 19.0 | 28.4 | 32.2 | 35.0 | 5000 | 160.0 | 20000 | 280.0 |
| 25 | 1 | 25.4 | 35.2 | 38.7 | 35.0 | 5000 | 160.0 | 20000 | 340.0 |
| 32 | 1-1/4″ | 31.8 | 41.9 | 45.5 | 35.0 | 5000 | 160.0 | 20000 | 460.0 |
| 38 | 1-1/2″ | 38.1 | 48.8 | 53.5 | 35.0 | 5000 | 160.0 | 20000 | 560.0 |
| 51 | 2″ | 50.8 | 63.2 | 68.1 | 35.0 | 5000 | 160.0 | 20000 | 700.0 |
MAIN FEATURES :
SAE 100R13. This hose shall consists of an inner tube of oil resistant synthetic rubber, multiple spiral plies of heavy steel wire wrapped in alternating directions, and an oil and weather resistant synthetic rubber cover.
APPLICATIONS :
This section covers hose for use with petroleum base hydraulic fluids.
WORKING TEMPERATURE :
From -40’C up to +121’C.
| DN | Hose I.D | Wire O.D | Hose O.D | Working Pressure | Burst Pressure | Minimum Bend Radius | |||
| inch | mm | mm | mm | Mpa | psi | Mpa | psi | mm | |
| 19 | 3/4″ | 19.0 | 28.4 | 32.2 | 35.0 | 5000 | 160.0 | 20000 | 280.0 |
| 25 | 1 | 25.4 | 35.2 | 38.7 | 35.0 | 5000 | 160.0 | 20000 | 340.0 |
| 32 | 1-1/4″ | 31.8 | 41.9 | 45.5 | 35.0 | 5000 | 160.0 | 20000 | 460.0 |
| 38 | 1-1/2″ | 38.1 | 48.8 | 53.5 | 35.0 | 5000 | 160.0 | 20000 | 560.0 |
| 51 | 2″ | 50.8 | 63.2 | 68.1 | 35.0 | 5000 | 160.0 | 20000 | 700.0 |
